LED-Tube 150 cm, T8, 29W, 3600lm, 80 degree, class E
METOLIGHT LED-Tube 150 cm, 29 W, 3600 lm, 80° beam
the ideal LED-tube for mounting heights of 4 m and above
Newly developed high-power LED tube designed for use in cross -field light strips ( eg supermarket , factory and warehouses ) with a particularly narrow light angle of about 80 °. The concentrated light, these LED tubes are particularly suitable for mounting heights of 4 m, because here about twice the brightness is achieved on the ground as comparable tubes with 120 ° angle of light.
The use of SMD 2835 latest technology with over 130 lm/W LED efficiency, aluminum core PCB, double-insulated compliant integrated power supply with short circuit protection and fluorescent tubes in the hard industrial applications make this LED tube over temperature protection the perfect substitutes conventional. 24 hours is common here.
With over 115 lm / W Lamp efficiency this LED tube reaches the energy efficiency class A ++ (EU 2012) E (EU 2019) and is more than twice as bright as conventional fluorescent tubes. They can be replaced without rewiring the light directly against the existing fluorescent tube , provided a KVG or VVG is installed as ballast. it must be replaced only the supplied LED starter against the existing fluorescent starter. For luminaires with electronic ballast but this must be clamped by an expert , go with then lost the existing certification mark of the lamp. The electrician must re-validate the CE conformity of the luminaire.
warranty: This LED tube we offer a 3 year warranty ( see warranty terms in the shop download area )
Asmetec Quality: Each tube is checked in Kirchheimbolanden for proper operation prior to shipment with us. You can request for free each batch a test report from our photometry. We create data for light calculation also in our own laboratory light - IES.
Technical data
| Beschreibung | Daten / Data | Description |
| Markenname | METOLIGHT | Brand name |
| Modell | LEDtube 150-T8-29W80 | Model |
| Betriebsspannung | 180 - 240 V AC / 50/60 Hz | Input Voltage |
| Gesamtleistung | ~ 29,4 Watt | Input Power |
| Leistungsfaktor | Pf > 0,90 | Power factor |
| Dimmbar? | nein / no | Dimmable? |
| Lichtquelle | EPISTAR SMD2835 | Light Source |
| Energieklasse | E | Energy Class |
| auf einer Skala von A bis G (wenig effizient) / on scale of A to G (less efficient) | ||
| Photobiolog. Klasse | 1 | Photobiolog. Class |
| Lichtwinkel | 80 | Beam Angle |
| Lichteffizienz | < 120 lm/W | Light Efficacy |
| Warmweiss | 2700 - 3000K - 3000 lm - Ra > 85 | Warm White |
| Naturweiß | 3800 - 4500K - 3100 lm - Ra > 85 | Nature White |
| Tagweiß | 4800 - 5500K - 3250 lm - Ra > 85 | Pure White |
| Kaltweiß | 5800 - 6500K - 3300 lm - Ra > 85 | Cold White |
| LED-Lebensdauer | < 40.000 h | LED-Life |
| Schaltzyklen (ein/aus) | > 120.000 | Switch Cycles (on/off) |
| Sockel | G13 | Base |
| Lampenkörper | Aluminium / PMMA | Bulb Body |
| Abmessung | 26 mm Durchmesser x 1498 mm lang (diameter x length) | Sizes |
| Gewicht | ~ 490 g | Weight |
| Normen | CE-Konformität / CE-conformity nach / acc to: EN55015:2013, EN60598-1:2009, EN60598-2-2:2012, EN60968:1990, EN60969, EN61000-3-2/2006, EN61000-3-3:2013, EN 61547:2013, EN62031:2013, EN62471:2008, EN62493:2010, EN62560:2012, ErP 2009/125/EU, NRS 2014/358/EU, EMV 2014/30/EU, RoHS 2011/65/EU | Standards |
| Toleranz techn. Daten | +/- 10% | Tolerance techn. Data |
| Hinweise | Notes |
| Verwendungszweck | Application |
| LED-Röhre als Retrofit für Leuchtstoffröhren für allg. Beleuchtungsanwendung im Innenbereich | LED-tube retrofit for common CFL-tubes, lighting application indoor |
| Besonderheiten | Specials |
| LED-Röhre mit eng gebündeltem Lichtstrahl, besonders geeignet für Montagehöhen über 4 m | LED-tube with narrow beam angle, particularly for mounting heights above 4 m |
| Installation | Installation |
| In Leuchten mit KVG/VVG und Fasssung G13 anstelle bisheriger Leuchtstoffröhren, Starter gegen LED-Starter austauschen, Lampenwechsel nur bei stromfrei geschalteten Leuchten vornehmen! | In luminaires with magnetic ballast and G13 socket to replace common CFL. Change existing starter by LED starter. Change tubes only when power is off |
| Hinweise | Notes |
| Wie bei allen LED-Leuchtmitteln ist auf ausreichende Luftzirkulation zu achten, damit die LED-Lampe nicht überhitzt. Die Gesamtenergieeffizienz und Lichtverteilung dieses LED-Leuchtmittels wird von der Bauart der Lichtanlage bestimmt, in der es verwendet wird. Messdaten unterliegen üblichen Toleranzen. Daten gem. Asmetec-Labor bzw. nach Werksangaben sowie. EU 874/2012, 2010//30/EU, 2011/65/EU | As with all LED-Lights take care for sufficient air ventilation to prevent LED overheating. The total efficiency and light distribution of this LED depends on the structure of the luminaire where it is used in. Technical data subject common tolerances. Measure data acc. Asmetec Test lab or original manufacturer data and acc. EU 874/2012, 2010//30/EU, 2011/65/EU |
| Entsorgung | Waste Treatment |
| LED-Leuchtmittel enthalten Wertstoffe. Bitte geben Sie die Lampen nach Gebrauch beim Wertstoffhof ab oder senden Sie sie an Asmetec zum Recycling zurück. | LED-lamps contain valuable raw materials. Please dispose them after use at the Local Court of Value Materials or return them for free disposal to Asmetec. |
| Prüfberichte | Test Reports |
| Individuelle Prüfberichte zu colorimetrischen, photometrischen und elektrischen, elektromagnetischen Daten erstellen wir auf Wunsch im eigenen Labor. | Individual test reports for colorimetric, photometric, electrical and electromagnetical data upon request made in own lab. |
