LED-Tube-ECO 60 cm, 10 Watt, T8-SMD, frosted, Class E
METOLIGHT LED-tube 60 cm, 10 W, 1000 lm, 140° beam
value priced LED-tube for linear fixtures and low mounting heights
low cost LED tube of latest technology for use in luminaires with low mounting height (eg office , iles...).
The use of latest technology SMD LEDs with about 110 lm/W LED efficiency, aluminum core printed circuit boards , insulated integrated power supply with short circuit protection, matted anti glare cover make this LED tube a perfect retrofit to common CFL tubes.
With about 100 lm / W Lamp efficiency this LED tube reaches the energy efficiency class A + (EU 2012) E (EU 2019) and is brighter than a common CFL tube while saving about 80% of energy
Ideal for light fixtures with magnetic ballast and starter - simply replace starter and tube - that's it.
For luminaires with electronic ballast but this must be rewired by an expert , go with then lost the existing certification mark of the lamp. The electrician must re-validate the CE conformity of the luminaire.
warranty:
This led tube , we provide a 2 year warranty ( see warranty terms in the shop download area )
Asmetec Quality:
Each tube is checked in Kirchheimbolanden for proper operation prior to shipment with us. You can request for free each batch a test report from our photometry. We create data for light calculation also in our own laboratory light - IES.
Technical Data
| Beschreibung | Daten / Data | Description |
| Markenname | METOLIGHT | Brand name |
| Modell | LEDtube 060-T8-10-ECO | Model |
| Betriebsspannung | 180 - 240 V AC / 50/60 Hz | Input Voltage |
| Gesamtleistung | ~ 10,3 Watt | Input Power |
| Leistungsfaktor | Pf > 0,90 | Power factor |
| Dimmbar? | nein / no | Dimmable? |
| Lichtquelle | EPISTAR SMD2835 | Light Source |
| Energieklasse | E | Energy Class |
| auf einer Skala von A bis G (wenig effizient) / on scale of A to G (less efficient) | ||
| Photobiolog. Klasse | 1 | Photobiolog. Class |
| Lichtwinkel | 140° | Beam Angle |
| Lichteffizienz | < 100 lm/W | Light Efficacy |
| Warmweiss | 2700 - 3000K - 900 lm - Ra > 75 | Warm White |
| Naturweiß | 3800 - 4500K - 940 lm - Ra > 75 | Nature White |
| Tagweiß | 4800 - 5500K - 950 lm - Ra > 75 | Pure White |
| Kaltweiß | 5800 - 6500K - 1000 lm - Ra > 75 | Cold White |
| LED-Lebensdauer | < 30.000 h | LED-Life |
| Schaltzyklen (ein/aus) | > 120.000 | Switch Cycles (on/off) |
| Sockel | G13 | Base |
| Lampenkörper | Aluminium / PMMA | Bulb Body |
| Abmessung | 26 mm Durchmesser x 598 mm lang (diameter x length) | Sizes |
| Gewicht | ~ 280 g | Weight |
| Normen | CE-Konformität / CE-conformity nach / acc to: EN55015:2013, EN60598-1:2009, EN60598-2-2:2012, EN60968:1990, EN60969, EN61000-3-2/2006, EN61000-3-3:2013, EN 61547:2013, EN62031:2013, EN62471:2008, EN62493:2010, EN62560:2012, ErP 2009/125/EU, NRS 2014/358/EU, EMV 2014/30/EU, RoHS 2011/65/EU | Standards |
| Toleranz techn. Daten | +/- 10% | Tolerance techn. Data |
| Hinweise | Notes |
| Verwendungszweck | Application |
| LED-Röhre als Retrofit für Leuchtstoffröhren für allg. Beleuchtungsanwendung im Innenbereich | LED-tube retrofit for common CFL-tubes, lighting application indoor |
| Besonderheiten | Specials |
| Besonders preiswerte LED-Röhre für allg. Beleuchtungsaufgaben | Value priced LED tube for common lighting applications |
| Installation | Installation |
| In Leuchten mit KVG/VVG und Fasssung G13 anstelle bisheriger Leuchtstoffröhren, Starter gegen LED-Starter austauschen, Lampenwechsel nur bei stromfrei geschalteten Leuchten vornehmen! | In luminaires with magnetic ballast and G13 socket to replace common CFL. Change existing starter by LED starter. Change tubes only when power is off |
| Hinweise | Notes |
| Wie bei allen LED-Leuchtmitteln ist auf ausreichende Luftzirkulation zu achten, damit die LED-Lampe nicht überhitzt. Die Gesamtenergieeffizienz und Lichtverteilung dieses LED-Leuchtmittels wird von der Bauart der Lichtanlage bestimmt, in der es verwendet wird. Messdaten unterliegen üblichen Toleranzen. Daten gem. Asmetec-Labor bzw. nach Werksangaben sowie. EU 874/2012, 2010//30/EU, 2011/65/EU | As with all LED-Lights take care for sufficient air ventilation to prevent LED overheating. The total efficiency and light distribution of this LED depends on the structure of the luminaire where it is used in. Technical data subject common tolerances. Measure data acc. Asmetec Test lab or original manufacturer data and acc. EU 874/2012, 2010//30/EU, 2011/65/EU |
| Entsorgung | Waste Treatment |
| LED-Leuchtmittel enthalten Wertstoffe. Bitte geben Sie die Lampen nach Gebrauch beim Wertstoffhof ab oder senden Sie sie an Asmetec zum Recycling zurück. | LED-lamps contain valuable raw materials. Please dispose them after use at the Local Court of Value Materials or return them for free disposal to Asmetec. |
| Prüfberichte | Test Reports |
| Individuelle Prüfberichte zu colorimetrischen, photometrischen und elektrischen, elektromagnetischen Daten erstellen wir auf Wunsch im eigenen Labor. | Individual test reports for colorimetric, photometric, electrical and electromagnetical data upon request made in own lab. |
